types of cleaning equipments suspended working platform

FOB Reference Price:Get Latest Price
US $1,800-2,600 / Set | 1 Set/Sets types of cleaning equipments (Min. Order)
Supply Ability:
5000 Set/Sets per Month types of cleaning equipments
Port:
Shanghai
Report Suspicious Activity
Overview
Quick Details
Place of Origin:
Shanghai, China (Mainland)
Brand Name:
RuiBiao
Model Number:
ZLP500/630/800/1000
Material:
Steel/Aluminium alloy/Steel with galvanized
lifting height:
300 maximum
Rated load:
500kg/ 630kg/ 800kg/ 1000kg
Voltage:
220-440V, 50-60Hz,3phase
Usage:
as a safe platform for people's high rise working
Application:
Building Facade Cleaning
Color:
Orange,Blue
Name:
Super September types of cleaning equipments suspended platform
Lifting speed:
8-10m/min
Surface treatment:
Plastic Spraying
Packaging & Delivery
Packaging Details
We packed types of cleaning equipments suspended working platform with Wooden cases or as your require.
Delivery Time
7-15 days after receiving you TT payment
Product Description

Product Application

Suspended platform is the latest products developed by RUIBIAO,with the features like more stable than elevator when start/stop,which greatly enhance the security and the service life of hoist and steel wire rope.The product has won the National hightech patent certificate.

ZLP Suspended Platform is a new decorating machinery, which can replace the traditional scaffold and is mainly used in decorating, cleaning and maintenance of external walls of high buildings, such as cement coating, wall brick coating, painting, glass installing, ship building and repairing, big vessels, bridges, dams, chimneys, etc. Using Balance suspended platform can reduce work intensity and raise work efficiency

Parameter of the suspended platform
Name
Technical parameter of construction platform
Model
ZLP500
ZLP630
ZLP800
ZLP1000
Rated load
500KG
630KG
800KG
1000KG
Lifting speed
8-10m/min
8-10m/min
8-10m/min
8-10m/min
Platform Dimension
5000(2+3m)×690*1450
6000(2*3m)×690*1450
7500(2.5m*3)×690*1450
7500(3*2.5)×690*1450
×1300
×1300
×1300
×1300
Lifting Height
100M
100M
100M
100M
Cable
100M
100M
100M
100M
Steel rope
Dia:8.3mm
Dia:8.3mm
Dia:9.1mm
Dia:8.6mm
Hoist
Power
1.5KW*2
1.5KW*2
1.8KW*2
2.2KW*2
Voltage
380V/50HZ
380V/50HZ
380V/50HZ
380V/50HZ
Safety lock
Permission force of
30KN
30KN
30KN
30KN
impact
3°~8°
3°~8°
3°~8°
3°~8°
Suspension mechanism
Front beam overhang
1.3~.1.5m
1.3~.1.5m
1.3~.1.5m
1.3~.1.5m
Galvanized
Support adjustable height
1.44~2.14m
1.44~2.14m
1.44~2.14m
1.44~2.14m
Counterweight
800KG
1000KG
1000KG
1200KG
20’ft container load qty
10 sets
10 sets
8 sets
8 sets
Type
A-alloy platform, Hot Dipping Platform, Steel platform

Main purposes of the suspended platform

Exterior wall construction and decoration of high-rise building, installation of panel wall and structural members of exterior wall.
Repair, maintenance and cleansing of exterior wall of high-rise building.
Construction, inspection, repair and maintenance of large project, for instance: chimney, dam, bridge and head frame.
Welding, cleansing and oil-painting of large ship.
Fabrication and installation of bulletin board on buildings at heights.

Drawing of gondola
Component Detailes

Suspended platform is mainly conmposed by suspension mechanism, hoist, safety lock, electric control box, working platform.
Its structure is reasonable and easy to operate. It can be make-up and break-out according to the actual need. The suspended platform is mainly used for refurbishment, decoration, cleaning and maintenance of high construction building

Machine Parts

Name: Hoist

Voltage: 220V/380V   Single-phase/Three-phase

Original: China

Hoist is a power component of suspension platform, and electric climbing structure is adopted.The hoist is driven by an electromagnetic brake three-phase asynchronous motor. After the worm gear and a pair of gears are decelerated, the hoist drives the wire rope conveyor to make the hoist along The work rope moves up and down so as to drive the suspension platform up or down.

Main Features

Name: Electric control box
Voltage: 220V/380V Single-phase/Three-phase
Original: China
The electric control box is used to control the movement of the suspension platform. The main components are mounted on an insulation board, a universal switch and a power indicator,Start button and emergency stop button device box door plate.

Machine Parts

Name: Bliwing Cylinder
Brand: RUIBIAO
Original: China
Safety lock is the protection device of suspension platform, when the wire rope suddenly broken or suspended platform is inclined to a certain angle, can automatically Secure the secure wire rope securely to ensure that the suspension platform does not fall or continue to tilt.

Main Features

Name: Suspension mechanism
Brand: RUIBIAO
Original: China
A suspension mechanism is a device that is mounted on top of a building and suspended from a suspension platform by means of a wire rope.

Main Features

Name: Suspension mechanism
Brand: RUIBIAO
Original: China

Specifications: 8.3mm/8.5mm
